Keyboard

---

Multi touch keyboard / Step key

---

Kick Generator

---

Type

Analog synthesis

---

Maximum Polyphony

1 voice

---

Structure

VCF (no input MS-20 Rev1 filter as resonator), Pulse Generator, VCA, analogue DRIVE, analogue TONE

---

MS-20 Resonator

Pitch/Octave, Bend, Time

---

Pulse

Colour, Level

---

Amp

Attack, Decay

---

Drive

---

---

Tone

Low Pass Filter, 12 db/oct

---

Sequencer

---

Number of Parts

1

---

Number of Steps

16

---

Number of Recording Patterns

16 (each with its own sound program)

---

Controls

Pattern Chain, Motion Sequence, Touch FX, Active Step, Accent (On/Off, Depth), Slide, Bend Reverse, Roll (1/4, 1/2, 1/1, 4/3, 2/1, 3/1), Octave (1 Oct Up, 2 Oct Up), Sustain, Swing

---

Connectors

---

Audio Output

Headphones (3.5mm stereo mini jack)

---

Sync

Sync In (3.5mm monaural mini jack, Maximum input level: 20V)
Sync Out (3.5mm monaural mini jack, Output level: 5V)

---

MIDI

In

---

Power

---

Power Supply

AA alkaline battery x 6 or AA nickel-metal hydride battery x 6
Or AC adapter (DC 9V) (optional)

---

Battery Life

Approximately 10 hours (using alkaline batteries)

---

Dimensions (W x D x H)

---

193 x 115 x 46 mm / 7.60” x 4.53” x 1.81”

---

Weight

---

377 g / 13.29 oz. (Excluding batteries)

---

Others

---

Included Items

AA alkaline battery x 6 (for verifying operation), Sync Cable

---

Accessories

AC adapter (DC 9V)
