- Effect Type
- SDD-3000, ANALOG, TAPE, MODERN, KOSMIC, REVERSE, PITCH, PANNING
- Input (0dBm=775mV)
- Input Level:
- -30dBm, -10dBm, +4dBm
- Max (Clip) Level (VR at 5):
- -13dBm, +7dBm, +21dBm
- Output (0dBm=775mV)
- Output Level:
- -20dBm, -10dBm, +7dBm
- Max (Clip) Level:
- -3dBm, +7dBm, +21dBm
- Frequency Response (Typ.)
- 10Hz ～ 20kHz:
- +0.5dB, -1dB (Direct)
- 10Hz ～ 17kHz:
- +0.5dB, -3dB (Effect: This frequency response is only when DELAY TYPE is set to SDD-3000.)
- Dynamic Range (Typ.)
- 110dB (Direct) A-Weighted
94dB (Effect) A-Weighted
- Filter
- Low CUT
- Turn over freq: 125Hz, 250Hz, 500Hz
Roll off: -3dB/OCT, -3dB/OCT, -3dB/OCT
- High CUT
- Turn over freq; 8KHz, 4KHz, 2KHz
Roll off; -6dB/OCT, -6dB/OCT, -6dB/OCT
- Modulation
- Frequency range: 0.0 (stop), 0.01Hz ~ 15Hz
Waveform (SINE, TRIANGLE, SQUARE, RANDOM, ENVELOPE)
Intensity
Delay type: KOSMIC, PITCH : -12 ~ 0 ~ +12, Others: 0.0 ~ 10.0
- Delay Time
- 1 ~ 4,000 milliseconds 1 millisecond step (With full bandwidth)
- Dimensions
(W x D x H) - 260 × 170 × 77 mm / 10.24″ x 6.69″ x 3.03″
- Weight
- 1.5 kg/3.31 lbs
- Power Supply
- AC Adapter (DC 9V)
- Current Consumption
- DC 9V 600mA
- Accessories
- DC9V AC Adapter
- Options
- XVP-10: Expression/Volume Pedal
EXP-2: Foot Controller
* All product, company, and standard names are trademarks or registered trademarks of their respective holders.
* Appearance and specifications of products are subject to change without notice.
